      Digitalization and automation

      E-health technology in renal care

      Digitalization and automation are powerful contributors in overcoming health-care challenges of today and tomorrow. NEXADIA® provides e-health technology for renal care centers enabling to have more time for patient care, creating modern working environment for clinical staff and contributing to improved therapy outcomes.

      Medical Professional

      This information is meant for medical professionals only. Please confirm that you are a medical professionals before accessing the information.

      Confirm Yes, I am a health care professional. Cancel No, I am not a health care professional.

      Technology for renal care

      Small helper allows flexibility

      A new generation of intelligent dialysis systems can simplify treatments for medical and nursing staff. Above all, the NEXADIA® mobile companion, which makes patient data available for mobile devices, can make care easier.

      A famale medical worker holds a tablet with NEXADIA® mobile companion open on it

      This questionnaire is supposed to provide support in configuring your system to achieve the best possible NEXADIA® performance. Please enter your current or desired system configuration and we will come back to you with an estimation if your system does support a NEXADIA® installation.

      1. Specification for NEXADIA® system

      The system requirements of NEXADIA® depend on the number of connected dialysis machines, the number of work stations and strongly on the number of patients. Please enter your center setup.

      2. System configuration

      The NEXADIA® system as a combination of software and hardware utilizes a configured network of at least one server and one workstation. To run NEXADIA® in a proper way each computer must meet the requirements. Ideally, you are able to run NEXADIA® and the corresponding database on two separate servers.

      2.1 Server configuration

      Please specify the configuration of the server that will run NEXADIA®.

      2.2 Client configuration

      Please specify the configuration of the work stations. Client support only for Windows 10.

      3. Windows account

      It is mandatory to create a local windows account with administrator privileges and permissions. This account must not be subject to password expiration and must be permanently on the server.

      4. SQL server

      Please specify the configuration of the server that will host the databases. It is mandatory to store the database content files (.mdf) and the database logfiles (.ldf) on separate physical hard disk drives. Alternatively, solid state drives may be used.

      5. Terminal server

      Please specify the configuration for your terminal server. Recommended minimum configuration for a terminal server in a typical NEXADIA® network with about 10 sessions.

      6. Virtual machines

      NEXADIA® can be installed on virtual machines. The following virtual machines are used:

      7. Your remarks



      B. Braun Indonesia is the responsible organization

      The protection of the personal data of our customers is very important to us and we take it very seriously. Your personal data is subject to data protection and will only be collected and stored for approach reasons. Under no circumstances will we pass on your personal data to third parties outside of the B. Braun group or use or store them for any other purposes. Our staff has been trained to handle personal data and is obliged to comply with the data protection regulations.

      check_circle

      Your request could not be submitted. Please try again.

      warning

      The following list gives an overview about the medical devices which are connectable to NEXADIA®. All the device interfaces are prepared to be connected to the BSL card reader for patient identification using the NEXADIA® patient cards.



      Medical scales

      • BERKEL (L130, L115, WI-127, L246, IT3000)
      • DETECTO (MedVue MV1, 758CSV)
      • DIGI (DI-10, DS-570)
      • METTLER (DT compatible, DIALOG mode compatible, SICS level 0 compatible, MMR compatible Models: DT DigiTOL, ID1, ID7, Spider, Spider-S, IND449, IND690, ICS429, IND890)
      • MICRA MetriPond (S100, S120)
      • ALTHIN (WTSW/B2.2/150/100)
      • RHEWA (82alpha, 83z, 83plus)
      • SCALETRONIX (6002, 6102)
      • SECA via seca 460 interface (63x, 64x, 68x, 70x, 727, 767, 910, 930, 95x)
      • SECA models with extension R including 635 r, 677 r, 685 r, 704 r
      • SOEHNLE (S20, 2720, 2760, 2763, 2780, 2790, 3020, 3030)
      • DIWAC (IT-1000)
      • CAE (A100 Indicator)
      • BIZERBA (ST)
      • PETERMANN / RINSTRUM (EDI03, R320, R323, R420)
      • GASSNER (DMA02)
      • PRECIA MOLEN (I 200 B/M)
      • DENSI (SI-1)
      • WEIGHTECH (WT1000-LED)
      • KERN (MPE 250K100HM)
      • GRAM (K2, K2E)



      Analysis devices

      • AVL/ROCHE-Diagnostics (OMNI Series, OMNI-S, OMNI-C, Cobas221)
      • SIEMENS/BAYER/CIBA/CHIRON BGA analyzers (RapidPoint 400, 405, 500, RapidLab 800, 855, 865, Series 200, System 248, 348)
      • IL GEM Premier 3000 (directly or with SynapseLink)
      • NOVA pHOx Plus monitors
      • RADIOMETER ABL analyzers (ABL5, ABL555, ABL615, ABL700, ABL715, ABL70, 77, ABL800)
      • IONOMETER2, IONOMETER3



      Blood pressure measurement devices

      • DINAMAP BP monitors (1846SX, 8100T, Compact, XL, Pro Series, ProCare)
      • DATASCOPE (Accutorr Plus)
      • WALCH ALLYN (Vital Signs Monitor)
      • OMRON (HBP 9020)



      Dialysis devices

      • Dialog+, Dialog Evolution, Dialog iQ
      • NIKKISO (DBB-05, DBB-07, DBB-EXA)
      • BAXTER (System 2000, Tina, Aurora), BAXTER/GAMBRO (AK100, AK200, AK200S, AK200S ULTRA, Artis)
      • FRESENIUS (2008H, 2008K)
      • FRESENIUS (4008, 5008) (Requires specific permission by FMC)
      • NIPRO (Surdial-X)



      Please note that some of the devices need a special hardware/software setup which is dependent on the manufacturing series.
      If you plan to connect a device please contact us first to check in detail if the connection with your specific device type and version is compatible in your country and setting.



      Device not listed?

      In general any device using a RS232 interface can be integrated. The specific adaption is done by a software driver module for the specific device. Many driver modules for common medical protocols like ASTM, LIS2, LIS3 and others are already existing, feel free to contact us about the terms of integrating new equipment.
