GN060

Bipolar coagulation in micro- and macro power range

Coagulation is an essential part of a surgical procedure. Vessel perforations, necrosis and tissue adhesions are herewith to be prevented.

Advantages

Advanced components

  • After switching on an automatic unit test is performed.
  • During operation all signals relevant to safety, operation of the function keys and the connected accessories are monitored.
  • Any irregularities are indicated to the user audibly and visually.

Micro and macro coagulation

  • MICRO power range: 0.1 to 9.9 watts, adjustable in 0.1 watt steps.
  • Extremely precise point coagulation without tissue adhesion is possible.
  • MACRO power range: 1 to 50 watts, adjustable in 1 watt steps.
  • Universal use of the bipolar coagulator.

Adaption

  • Automatically adaptation to different tissue impedance levels, both in micro and macro ranges.

Memory function

  • Individual, indication-specific empirical values can be stored in 4 memory locations and then called up quickly with the push of a button when required.

Automatic start function (optional)

  • If desired the generator switches itself on automatically as soon as the forceps tips come into contact with tissue.
  • The generator is switched on by operating of the foot switch if the automatic start function is not activated.

Remote control (optional)

  • Cable-free infrared remote control also permits switching of the output power (4 memories) by the operating surgeon under sterile conditions.

International safety standards

  • Compliance with national and international regulations is confirmed by test institutes.

Range of Application

  • Microsurgery
  • Neurosurgery
  • Plastic & Reconstructive Surgery
  • ENT Surgery
  • Ophtalmology
  • Pediatric Surgery
  • Gynaecology
  • Laparoscopy

Note

Liquid-assisted coagulation in combination with the Jet Irrigation System.
